Deskripsi Produk V9
- Jarak Frekwensi : VHF 136 – 174 Mhz – UHF High 400-480 Mhz
- Power : VHF 5 Watt
- Baterai Li – ion 1600 mA
General Specifications
- Operating Temperature : 20C ~ 50C
- Operating Voltage : DC 7.2V
- Operating Mode : Frequency simplek and different frequency simplex
- Size Dimension : 100mm X 55mm X 32mm ( Without Antenna )
- Weight : About 220g ( Included Battery )
- Antenna Impedance : 50 Ohm
- Transmiter Spesifications :
- Output Power : 5.5W
- Frequency Stability: 2.5ppm
- Max Frequency Deviation : 5Khz
- Audio Distortion : 3%
- Modulation Character : 3dB~ 3dB
- Adjacent Channel Power: 65dB
- Spurious Radiation : 7.5 Hz
- Occupation Bandwitch : 16KHz
- Receiver Spesifications :
- Sensitivity : 0.18
- Audio Distortion : < 3%
- Audio Response : < 2dB~ 10dB
- Channel Inhibition : < -8dB
- Adjacent Channel Selectivity : 55dB
- Intermodulation Rejection : 55dB
- Spurious Response : 55dB
- Blocking : 85dB
