Shakespeare 393 Antena SSB
Shakespeare 393 Antena SSB, whip antenna with conductors running full length. In brief, no loading coil.
Three section convenience, that is in an outstanding performer. Shakespeare 393 antenna is electrically the same as the industry standard Style 390, but the design is in three sections. For use in calm to moderate seas. Reinforced insulating qualities allow input power up to 1 kw. Conductors are permanently sealed in Shakespeare white fiberglass Chrome plated brass ferrule with standard 1 in 14 thread.
- Side feed termination band as well as come with three sections
- Power input is up to 1 kw
- Suggested mount: Style 409-R or 410-R Mounting Kit. Additionally each sold separately, use them for deck or side mounting.
- 3 Sections: base 92 in; center 92 in; tip 92 in
Additionally best applications include calm to moderate seas.
Suggested mount(s): 409-R as well as 410-R
Shakespeare 393 Specifications |
|
| Band: | SSB |
| Max. Input Power: | 1000 Watt |
| SSB: | Frequency: 2 – 30 MHz with tuner |
| Bandwidth: | Resonant Frequency: 10.8 MHz |
| Ferrule: | Chrome plated brass |
| Color / finish: | White |
| Limited Warranty:> | 1 years |
