HT BEARCOM BC-UV5R Dual Band
HT BEARCOM BC-UV5R HT Dual Band Professional FM Transceiver Specifications:
- Dual band (135-175 MHz ; 400-438 MHz)
- Dual display
- Dual standby
- 128 Memory Channels
- Easy Shortcut menu operation mode
- Band selective (25 KHz / 12.5 KHz)
- Chinese / English voice prompt
- Built in CTCSS / DCS and auto scan
- 25 memory radio stations
- PTT ANI ID code
- VOX function
- FM radio
- Tri-color backlight
- 1750 Hz tone
- Emergency alarm
SPECIFICATIONS
| General | |
| Frequency Range | 65-108 MHz (FM Receive only) |
| 136-174 MHZ and 400-520 Hz (TX / RX) | |
| Channel No. | 128 |
| Frequency Stability | ±2.5 ppm |
| Antenna | High gain Dual Band antenna |
| Antenna Impedance | 50 Ω |
| Operating Voltage DC | 7.4 V |
| Mode of operation | Simple or semi duplex |
| Dimension W x H x D | 100 x 52 x 32 mm |
| Weight | 250 g (including battery as well as antenna） |
| Transmitter | |
| Output power | 4 W / 1 W (Max. 5 W) |
| Modulation Mode | 16kΦF3E / 11kΦF3E |
| Maximum deviation | ＜5 kHz (Wide) / ＜2.5k Hz (Narrow) |
| Spurious Radiation | ＜7 μW |
| Adjacent Ch. power | ≤ -65 dB (Wide) / ≤ -60dB (Narrow) |
| Pre-emphasis characteristics | 6 dB |
| Current | ≤1.6 A (5 W) |
| CTCSS/DCS deviation | 0.5 ± 0.1 kHz (Wide) / 0.3 ± 0.1 kHz (Narrow) |
| Intermediation sensitivity | 8-12 mv |
| Intermediation distortion | ＜10% |
