Icom IC-M506

Icom IC-M506

Icom IC-M506

Icom IC-M506 VHF Marine Transceiver dikemas penuh dengan fitur termasuk Integrated AIS Receiver, konektivitas NMEA2000, fungsi rekaman suara 'Last Call', teknologi 'Active Noise Cancelling' ditambah user interface berbasis menu intuitif dan tampilan dot matrix yang besar sehingga sangat mudah untuk digunakan.

Icom IC-506 submersible,  memenuhi IPX 8 Advanced Waterproof  / Submersible Plus, bisa bertahan di kedalaman 1 meter air selama 60 menit.

ICOM

Description

Icom IC-M506 VHF Marine Transceiver with NMEA 2000 connectivity and AIS receiver

The IC-M506 is packed full of features including integrated AIS receiver, NMEA2000 connectivity, ‘Last Call’ voice recording function, ‘Active Noise Cancelling’ technology plus Icom’s new intuitive menu-driven user interface and large dot matrix display making it really easy to use.

Integrated AIS Receiver

The M506’s with the integrated AIS receiver can show AIS vessel traffic information on the display. The AIS target call function allows you to easily set up an individual DSC call. The Plotter, Target list and Danger list can be toggled on the display.

NMEA Connectivity
A typical installation will connect to your chart plotter using the NMEA2000™ protocol for AIS data transfer. This allows you to overlay received AIS data onto your chart plotter from your radio.

NMEA 0183 is used to interface GPS position data and received DSC information with your chart plotter. The IC-M506EURO can receive and transmit GPS (position, course (COG) and speed (SOG)), AIS report and DSC call information data and transmit radio frequency and PGN list data over the NMEA network.

Last Call Voice Recording
The last call voice recording function automatically saves the last two minutes of the last incoming call. You can re¬play the received call, and not miss any incoming call.

Active Noise Cancelling
Using digital signal processing technology, the built-in bidirectional active noise cancelling provides superb performance. It reduces background noise to up to 90% in the received signal and 30% fixed in the transmit¬ting signal. The function OFF setting is also possible.

Intuitive Menu-Driven User Interface
The intuitive software key functions provide easy and fast operation to control the multiple functions of the IC-M506EURO. The bottom line of the dot-ma¬trix display shows the software key functions which can be toggled with the left and right buttons.

25W Two-Way Hailer
When connected to an external hailer horn, you can talk to people on the deck or shore from the radio’s mi¬crophone and can hear people’s reply via the hailer speaker. The RX hailer function allows you to monitor the received audio from the hailer horn. 25W amplifier increases your talk power making your communication loud and clear.

Built-in Horn (Automatic & Manual)
Foghorn feature is built-in via the external Hailer horn. Four horn patterns are selectable for the automatic horn function.

ITU Class D DSC (Meets ITU-R M493-13)
The built-in DSC watch function monitors Ch. 70 (DSC channel) activity, even while you are receiving another channel. DSC functions include: distress, individual, group, all ships, urgency, safety, position request/report, polling re¬quest and DSC test calls. Up to 100 DSC address IDs can be programmed.

Rear Microphone Version*
With this version, the microphone connector is drawn from the rear panel and a 6.1m (20ft) microphone extension cable i s supplied to allow you clean and neat panel installation.
* Ask your dealer for details.

IPX8 Advanced Waterproof
The IC-M506EURO and supplied HM-205B/RB microphone can withstand 1m (3.2ft) depth of water for 60 minutes.

Other Features
• Simple remote control speaker-microphone, HM-205B/RB
• 15W audio output power (with external speaker)
• AquaQuake™ draining function
• Optional voice scrambler, UT-112 for private conversation
• MA-500TR AIS transponder and MarineCommander™ compatible

Brand

ICOM

ICOM

Spesifikasi

General

IC-M506

Frequency range Tx 156.025–157.425MHz
Rx 156.050–163.275MHz
CH70 156.525MHz
AIS1, 2 161.975, 162.025MHz
Usable channels USA, CAN, INT, WX channels
Type of emission 16K0G3E (FM), 16K0G2B (DSC)
Power supply requirement 13.8V DC (11.7–15.9V DC)
Current drain
(at 13.8V DC)
Tx 25W output 5.5A
Rx AF Max External SP 5.0A (RX hailer ON)
Internal SP 1.5A
Operating temperature range -20°C to +60°C;
-4°F to +140°F
Antenna impedance 50 Ohms (SO-239)
Dimensions (W×H×D)
(Projections not included)
178.9×113.9×113.8 mm;
7.04×4.48×4.48 in
Weight (approx.) 1400g; 3.09lb

Transmitter

IC-M506

Output power (at 13.8V DC) 25W, 1W
Max. frequency deviation ±5.0kHz
Frequency tolerance ±10ppm
Spurious emissions Less than 70dBc (at 25W)
Residual modulation More than 40dB
Adjacent channel power More than 70dB

Receiver

IC-M506

Intermediate frequency
CH70
1st 30.15MHz, 2nd 450kHz
1st 21.7MHz, 2nd 450kHz
Sensitivity (at 12dB SINAD) 0.22 µV typical
Adjacent channel
selectivity CH70 (1% BER)
More than 75dB
More than 73dB emf
Spurious response
CH70 (1% BER)
More than 75dB
More than 73dB emf
Intermodulation
CH70 (1% BER)
More than 75dB
More than 68dB emf
Hum and noise More than 40dB
Audio output power
(at 10% distortion)
More than 15W with a 4 Ohms
RX speaker

Applicable U.S. Military Specifications

Icom makes rugged products that have been tested to and passed the following MIL-STD requirements and strict environmental standards.

Standard MIL-810 G
Method, Proc.
Low Pressure Storage 500.5 I
Low Pressure Operation 500.5 II
High Temperature Storage 501.5 I
High Temperature Operation 501.5 II
Low Temperature Storage 502.5 I
Low Temperature Operation 502.5 II
Temperature Shock 503.5 I-C
Solar Radiation 505.5 I
Rain Blowing 506.5 I
Humidity 507.5 II
Salt Fog 509.5
Dust Blowing 510.5 I
Water Immersion 512.5 I
Vibration 514.6 I
Shock Functional 516.6 I
Shock Transit Drop 516.6 IV

Also meets equicalent MIL-STD-810-C, -D, -E and -F.



Applicable IP Rating and environmental test.

Ingress Protection Standard
Water IPX8 (1m depth water for 60 minutes)
