Antena Celwave PD220 dengan gain 5,25dB cocok digunakan sebagai antena base station, antena repeater dan antena radio komunikasi lainnya.

Description



PD220Series
136-281 MHz Super Stationmaster™ Omni Fiberglass Antenna





Super Stationmaster VHF base station antennas incorporate the design features of 9 MHz broadband capability, improved lightning protection and true omnidirectional gain in excess of 5 dBd.

The PD620 represents an extra-rugged version of the PD220, with specially strengthened housing and support pipe for use in very severe environments.Note: Below 150 MHz, rated gain for both antennas is 4.8 dBd due to length constraints. Side mounting hardware is available for the PD220 to achieve special radiation patterns.The PD555 reflector assembly may be utilized with the PD220 for both side and top mounted installations. Vertical Beam Downtilt: the PD220-DT may be ordered with 3? or 6? downtilt. Note: Operational gain and bandwidth are lessened with downtilt. The PD220-DT is both reduced to 5.0 dBd gain and 1.5 MHz bandwidth. When downtilt antennas are ordered, exact frequency must be specified.Fiberglass construction
Protects radiating elements in corrosive environments.
DC grounded
Affords lightning protection.
Copper radiating elements
Minimizes possibility of intermod generation.

Order Information



Item Number

Frequency Range MHz

PD220-DT 136 – 174
PD220-1 136 – 141
PD220-2 142 – 150
PD220-3A 150 – 158
PD220-3B 152 – 160
PD220-4 155 – 163
PD220-5 157 – 165
PD220-6 160 – 169
PD220-7 165 – 174
PD220-8A 216 – 221
PD220-8 216 – 225
PD220-8B 220 – 225
PD220-9 279 – 281







Brand

CELWAVE

Spesifikasi

PD220 Series *Specifications*

ELECTRICAL SPECIFICATIONS

PD220-1

PD220-2

PD220-3A

PD220-3B

PD220-4

PD220-5

Frequency Range- MHz

136-141

142-150

150.5-158.5

151.5-159.5

155-163 157-165

Gain – dBd (dBi)

5.25 (7.4)

Bandwidth – MHz for 1.5:1 VSWR

5

8

Vertical Beamwidth – Degrees

18

Polarization

Vertical

Maximum Power Input – Watts

500

Electrical Tilt – Degrees

0

Lightning Protection

Direct Ground

Termination – Direct Fixed

UHF-female

Flexible Extension

18” RG8 N-Male
UHF-Male

ELECTRICAL(cont.)

PD220-6

PD220-7

PD220-8

PD220-8A

PD220-8B

PD220-9

PD220-DT

Frequency Range – MHz

160-169 165-174

216-225

216-221

220-225

279-281

136-174

Gain – dBd (dBi)

5.25 (7.4)

6 (8.1)

5.0 (7.1)

Bandwidth – MHz for 1.5:1 VSWR

9

5

2

1.5

Vertical Beamwidth – Degrees

18

16

18

Polarization

Vertical

Maximum Power Input – Watts

500

Electrical Tilt – Degrees

0

3,6

Lightning Protection

Direct Ground

Termination – Direct Fixed

UHF-female

Flexible Extension

18” RG8 N-Male
UHF-Male


MECHANICAL SPECIFICATIONS

PD220-1

PD220-2

PD220-3A

PD220-3B

PD220-4

PD220-5

Overall Length- ft.(m)

20.0(6.1)

19.2(5.87)

20.7(6.31)

20.8(6.35)

20.2(6.14)

20.0(6.1)

Element Housing Length- ft.(m)

17.6(5.37)

16.8(5.13)

18.6(5.66)

18.6(5.66)

17.9(5.47)

17.8(5.42)

Support Pipe Diameter- in.(m)

2.75(0.07)

Support Pipe Length- ft.(m)

2.33(0.71)

2.25(0.69)

2.17(0.66)

Weight- lbs(kg)

25(11.3)

24(10.8)

22(10.0)

Radiating Element Material

Copper

Element Housing Material

Fiberglass

Support Pipe Material

Aluminum Alloy

Max Wind Loading Area
(Flat Plate Equivalent)- ft2(m2)

2.27(.211)

2.17(.202)

2.34(.217)

2.26(.210) 2.24(.208)

Rated Wind Speed – mph (km/hr)

100(161)

Bending Moment @ Rated Wind
1 in. Below Top of Support Pipe ftlbf(N m)

808(1095)

738(1000)

882(1196)

813 (1102) 809 (1096)

Side Thrust @ Rated Wind – lbf (N)

91(405)

87(387)

94(418)

90 (400)

Mounting Hardware- Supplied

PD46

Mounting Hardware- Optional

PD241, PD246, PD556,PD503, PD561

MECHANICAL (cont.)

PD220-6

PD220-7

PD220-8

PD220-8A

PD220-8B

PD220-9

PD220-DT

Overall Length- ft.(m)

19.5(5.94)

19.0(5.79)

18.8 (5.73)

15.1 (4.62)

20.0 (6.1)

Element Housing Length- ft.(m)

17.4(5.31)

17.0(5.17)

16.6(5.05)

12.9(3.93)

17.6(5.37)

Support Pipe Diameter- in.(m)

2.75 (0.07)

Support Pipe Length- ft.(m)

2.08(0.64)

2.25 (0.69)

2.33 (0.71)

Weight- lbs(kg)

22(10.0)

21 (9.5)

23 (10.5)

Radiating Element Material

Copper

Element Housing Material

Fiberglass

Support Pipe Material

Aluminum Alloy

Max Wind Loading Area
(Flat Plate Equivalent)- ft2(m2)

2.20(.204)

2.14(.199)

2.12(1197)

1.77(0.16)

1.72(.160)

2.27 (.211)

Rated Wind Speed- mph(km/hr)

100 -161

Bending Moment @ Rated Wind
1 in. Below Top of Support Pipe ft lbf(N m)

773 (1048)

738 (1001)

713(966)

595(807)

451(611)

808 (1096)

Side Thrust @ Rated Wind- lbf(N)

88 (391)

86 (383)

85(377)

71(315)

69(307)

91 (404)

Mounting Hardware- Supplied

PD46

Mounting Hardware- Optional

PD241, PD246, PD556,PD503, PD561


SHIPPING SPECIFICATIONS

PD220-1

PD220-2

PD220-3A

PD220-3B

PD220-4

PD220-5

Shipping Weight- lbs.(kg)

57.0 (25.9) 4

8.0 (21.7)

55.0 (24.9)

57.0 (25.9)

51.0 (23.1)

Shipping Dimensions of Antenna- WxDXH- ft.(m)

22.3×0.33×0.33
(6.8×0.10×0.10)

21.0×0.33×0.33
(6.4×0.10×0.10)

22.0 x 0.33 x 0.33
(6.7 x 0.10 x 0.10)

Shipping Dimensions of Accessory -WxDxH

Packed w/antenna

Shipping Mode

Common Carrier

SHIPPING (CONT)

PD220-8B

PD220-6

PD220-7

PD220-9

PD220-8

PD220-8A

PD220-DT

Shipping Weight-lbs.(kg)

57.0 (25.9)

40.0(18.1)

57.0 (25.9)

51.0 (23.1)

58 (26.4)

Shipping Dimensions of Antenna
WxDXH- ft.
(m)

21.0×0.33×0.33
(6.5×0.10×0.10)

20.8×0.33×0.33
(6.4×0.10×0.10)

16.8X0.33X0.33
(5.1X0.10X0.10)

21.0×0.33×0.33
(6.5×0.10×0.10)

23.0×0.33×0.33
(7.0×0.10×0.10)

Shipping Dimensions of Accessory
WxDxH – ft. (m)

Packed w/antenna

Shipping Mode

Common Carrier

PD220 Horizontal Pattern

PD220 Vertical Pattern

PD220 Horizontal

PD220 Vertical
